Introduction to conventional fabric varieties, specifications and uses–A must-read composite fabric information for textile people

Introduction to conventional fabric varieties, specifications and uses–A must-read for textile people 1 Polyester taffeta, taffeta, polyester plain spinning, Polyester spinning POLYESTERTAFFETA Plain weav…

Introduction to conventional fabric varieties, specifications and uses–A must-read for textile people


Polyester taffeta, taffeta, polyester plain spinning, Polyester spinning POLYESTERTAFFETA

Plain weave polyester

Warp and weft: 68D/24FFDY 100% polyester semi-gloss plain weave fabric.

Mainly include: 170T, 190 T, 210 T, 240 T, 260 T, 300 T, 320 T, 400 T

T: The sum of longitude and latitude density in units of inches, such as 190T That is, the sum of the longitude and latitude densities is 190 (actually it is generally less than 190).

Use: Generally used as lining



Nice spinning ( Nylon taffeta) NYLONTAFFETA

Plain weave nylon

Use 70D or 40D nylon FDY for warp and weft,

Density: 190T-400T

There are many derivatives of nylon spinning, all called nylon spinning, including twill, satin, plaid, jacquard, etc.

Usage: Men’s and women’s clothing fabrics. Coated nylon is airtight, watertight, and down-proof, and is used as fabric for ski jackets, raincoats, sleeping bags, and mountaineering clothing.


Polyester PONGEE

Plain weave polyester

At least one of the warp and weft is low elastic (network) yarn


The warp and weft of all stretch yarns are called full stretch pongee, and the radial filaments are called semi-elastic pongee

The original pongee was a plain weave, and now there are many derivatives and specifications. Full, density from 170T to 400T

There are semi-gloss, matt, twill, point, strip, flat grid, floating grid, diamond grid, football grid, waffle grid, oblique grid, plum blossom grid…

Usage: “Semi-elastic pongee” fabric has been used to make lining accessories for suits, suits, jackets, children’s clothing, professional wear, etc.; “full-elastic pongee” can be used to make down jackets and casual jackets , children’s clothing, etc., waterproof coated fabrics can also be used to make waterproof clothing, umbrellas, ponchos, awnings, etc.



Oxford cloth OXFORD

Plain weave polyester, nylon

At least 150D in warp and weft

Polyester Oxford cloth: filament, elastic yarn, high elastic yarn

Nylon Oxford cloth: filament, velvet Oxford cloth, nylon cotton Oxford cloth

Common ones are:

150D*150D, 200D*200D, 300D* 300D, 150D*200D, 150D*300D, 200D*400D, 600D*600D, 300D*450D, 600D*300D, 300D*600D, 900D*600D, 900D*900D, 1200D*1200D, 1680D, various jacquards

Usage: Mainly used to make bags



Plain weave is generally nylon, but also polyester

Use ATY in the latitudinal direction, and the latitudinal D number is at least twice the radial D number.

General: nylon velvet, 70D nylon FDY*160D nylon ATY, density: 178T, 184T, 196T, 228T

A variety of plaid, twill, and jacquard velvet are available


Uses: jackets, clothing fabrics, bags, etc.



Plain weave polyester

Weak twist in weft direction

Radial direction: 75D DTY network yarn or 75D FDY

Weft direction: 150DDTY 8T/2S2Z – (8 twists, 2 left and 2 right twists)

Divided into full elastic Huayao and half elastic Huayao

Gao Si Bao: Radial: 75D DTY network yarn

Weft: 150D DTY 22T/2S2Z

Kosibao weft reinforced twist

Washed velvet: Radial: 50DFDY+50DPOY

Weft: 150DDTY 8-12T/2S2Z

Uses: Clothing fabrics, bags, etc.


Imitation silk series IMITATIONSILK

Plain weave polyester


Both warp and weft are twisted, 2S2Z arrangement

75D Georgette: 75DFDY18T/2S2Z * 75DFDY 18T/2S2Z

Put 17#*2 into the machine–( No. 17 reed is worn twice, that is, the machine is secreted 34)

Regular: 50D Georgette, 75D Georgette, 100D Georgette, 150D Georgette


The warp and weft are both twisted, arranged in 2S2Z

75D chiffon: 75DFDY22T/2S2Z * 75DFDY 22T/2S2Z

Put 19#*2 into the machine–( No. 19 reed is worn twice, that is, the warp density of the machine is 38)

Conventional: 30D, 50D, 75D, 100D, 150D

Derivatives: Carisan, Orly yarn. . .

Chiffon is very similar to Georgette. Chiffon has higher twist and higher density than Georgette


Radial centering Twist (about 18T), plus a strong twist in the weft direction (about 28T)

75D smooth crepe: 75DFDY* 75DFDY 28T/S

Conventional: 50D*50D, 75D* 75D, 75D*100D, 100D*100D

Mainly depends on the style

Usage: summer women’s clothing



Peach skin velvet MICROPEACH

Plain weave, twill, satin weave, polyester, nylon polyester

Peach skin velvet is made of ultra-fine A thin sanded fleece fabric woven from synthetic fibers. The surface of the fabric is covered with a particularly short, fine and fine velvet. It has moisture-absorbing, breathable and waterproof functions and a silk-like appearance and style. The fabric is soft, shiny and has a smooth and waxy feel.

Weft direction 150D/144F or 288F Fine denier fiber

Radial direction: 75D/36F or 72F DTY network yarn

Weft direction: 150D/144F or 288F DTY network silk

Due to the fine denier fiber, after peach skin is sanded, the hair feels fine

Usage: beach pants, clothing (jackets, skirts, etc.) fabrics, can also be used As a decoration for bags, shoes and hats, and furniture



Satin weave

Mainly divided into warp suede and weft suede

Warp suede: use island composite yarn in the warp direction, and general polyester in the weft direction Elastic yarn

Regular: 105D*75D, 105D*150D, 105D*200D, 105D*300D, 105D*400D, 105D*450D, 105D*600

Weft suede: diameter General stretch yarn, weft island composite yarn

Conventional: 75D*160D, 75D*225D

Uses: curtains, home textiles, shoe materials, sofa covers, decorative fabrics, women’s spring and autumn etc.


Glass yarn ORGANDY

Plain weave nylon

Use 20D or 30D monofilament for warp and weft, low warp density, low weft Dense, sparse density, thin texture, clear step holes, refreshing feel, elasticity, good breathability, and comfortable to wear.

Uses: summer shirts, skirts, pajamas, headscarves, veils and embroidered base fabrics, lampshades, curtains.



Plain weave

Has a two-color effect, known as the chameleon

Warp nylon, weft polyester, plain weave. There are also full polyester ones, which use a cationic yarn to produce a two-color effect.

General: 70D*75D, 70D*150D (thickened), density: 170T, 190T, 210T, 230T, 300T

Uses: home textiles, curtains, clothing materials.


Gabardine (polyester) GABARDINE

Twill weave

Warp and weft stretch yarn, twill weave

Conventional: 150D*150D, 150D*200D, 150D*300D

Usage: workwear, clothing, etc.


Shu Mei Silk poly twill lining

Twill weave 2/1 twill polyester

Radial filament, weft elastic Silk

Regular: 68DFDY*75D DTY

Usage: lining


Beautiful silk twill rayon lining

Twill weave 2/1 twill polyester or rayon

Full-length warp and weft yarn

Conventional: 68DFDY*68D FDY or 108D FDY

Usage: lining



Satin weave polyester

Classification: untwisted satin, twisted satin; glossy Satin, matte satin;

Jingyue Satin: 50D*50D, 50D*75D untwisted satin

Static band: 50D*50D, 50D*75D twisted color Ding

Wumei satin: 75D*100D untwisted satin

Gong satin: 75D*150D, 75D*200D, 75D*300D untwisted or twisted satin

Uses: dresses, stage cloths, evening wear, linings, luggage materials, etc.
